EKF
Residual current circuit breaker DV 2P (S) 25A 300mA type AC electromechanical 10kA selective AVERES EKF rccb-2-25-300-s-av
SKU: rccb-2-25-300-s-av
ETIM: EC000003
14,426 ₽
Get back 144 ₽ in points
Analogues by specifications
No description available
Additional equipment possible
Yes
Mounting installation depth
74 мм
Number of poles
2
Rated breaking capacity in accordance with EN 60898
10 кА
Rated ultimate breaking capacity (Icw)
10 кА
Rated impulse voltage
4 кВ
Rated voltage
230 В
Rated insulation voltage Ui
660 В
Rated current
25 А
Rated leakage current
0.3 мА
Ambient operating temperature to
50 град.C
Ambient operating temperature from
-25...50 град.C
With short-time delayed tripping
Yes
With interlock device
No
Selective protection
Yes
Flexible stranded conductor cross-section up to
16 кв.мм
Stranded flexible conductor cross-section from
1...16 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
1...25 кв.мм
Mounting method
DIN rail
Pollution degree (number)
2
IP protection rating
IP20
Residual current type
AC (alternating)
Resistance to current surges
10 кА
Frequency (Hz)
50/60 Hz
Width in modular units
2
