Эра
Residual current device (RCD) 2p 25A/30mA VD-40 (electronic) SIMPLE-mod-42 ERA Б0039262
SKU: Б0039262
ETIM: EC000003
824 ₽
Get back 8 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
No description available
Additional equipment possible
No
Mounting installation depth
68 мм
Number of poles
2
Rated breaking capacity in accordance with EN 60898
6 кА
Rated ultimate breaking capacity (Icw)
6 кА
Rated impulse voltage
0 кВ
Rated voltage
230 В
Rated insulation voltage Ui
230 В
Rated current
25 А
Rated leakage current
.03 мА
Ambient operating temperature to
40 град.C
Ambient operating temperature from
-25 град.C
Leakage current adjustment
No
Adjustable delay time
No
With short-time delayed tripping
No
With interlock device
No
Selective protection
No
Flexible stranded conductor cross-section up to
25 кв.мм
Stranded flexible conductor cross-section from
1 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
1 кв.мм
Mounting method
DIN rail
Pollution degree (number)
2
IP protection rating
IP20
Installation size (in accordance with DIN 43880)
0
Residual current type
Alternating current (AC)
Resistance to current surges
.25 кА
Frequency (Hz)
50 Hz
Width in modular units
2
