Screw connector terminal ZVI-20 flame-retardant 4.0-10mm2 12 pairs yellow IEK UZV7-020-06
SKU: UZV7-020-06
ETIM: EC001284
228 ₽
Price list (incl. VAT):
259 ₽
Preorder
Order multiple: 10
The clamp is designed for screw connection of conductors, protecting the wire from damage and eliminating the possibility of a short circuit to the electrical installation enclosure. The insulation frame is made of white non-flammable polystyrene.
| Height | 17 мм |
| Height | 17 мм |
| Length | 138 мм |
| Length | 138 мм |
| Permissible continuous current | 20 |
| Climatic version | UKhL3.1 |
| Number of terminals per pole | 2 |
| Number of poles | 12 |
| Max. operational voltage Ue | 400 |
| Clamping bracket material | Brass |
| Housing insulation material | Polystyrene |
| Housing material | Polystyrene |
| Housing material | Polystyrene |
| Tightening torque Nm at conductor cross-section | 1.2 |
| Rated voltage | 400 В |
| Rated insulation voltage Ui | 450 В |
| Rated current In | 20 А |
| Transparent | No |
| Operating temperature | 110 град.C |
| Operating temperature from | -25...110 град.C |
| Connection position | Side (transverse) |
| Flame propagating | No |
| Flexible stranded conductor cross-section up to | 10 кв.мм |
| Stranded flexible conductor cross-section from | 4...10 кв.мм |
| Solid conductor cross-section to | 10 кв.мм |
| Solid conductor cross-section from | 4...10 кв.мм |
| Mounting method | Direct mounting |
| IP protection rating | IP00 |
| Product/component type | ZVI terminal block |
| Electrical connection type 1 | Screw connection |
| Electrical connection type 2 | Screw connection |
| Color | Yellow |
| Colour | Yellow |
| Width | 23 мм |
| Width/connection pitch | 23.0 мм |
