Screw terminal block ZVI-3 flame-retardant 1.0-2.5mm2 12 pairs blue IEK UZV6-003-04
SKU: UZV6-003-04
ETIM: EC001284
850 ₽
Get back 8 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 10 шт
Analogues by specifications
Stock by warehouse
The clamp is designed for screw connection of conductors, protecting the wire from damage and eliminating the possibility of a short circuit to the electrical installation enclosure. The insulation frame is made of white non-flammable polystyrene.
Height
11 мм
Height
11 мм
Length
92 мм
Length
92 мм
Permissible continuous current
3
Climatic version
UKhL3.1
Number of terminals per pole
2
Number of poles
12
Max. operational voltage Ue
400
Clamping bracket material
Brass
Housing insulation material
Polystyrene
Housing material
Polystyrene
Housing material
Polystyrene
Tightening torque Nm at conductor cross-section
0.8
Rated voltage
400 В
Rated insulation voltage Ui
450 В
Rated current In
3 А
Transparent
No
Operating temperature
110 град.C
Operating temperature from
-25...110 град.C
Connection position
Side (transverse)
Flame propagating
No
Flexible stranded conductor cross-section up to
2.5 кв.мм
Stranded flexible conductor cross-section from
1.0...2.5 кв.мм
Solid conductor cross-section to
2.5 кв.мм
Solid conductor cross-section from
1.0...2.5 кв.мм
Mounting method
Direct mounting
IP protection rating
IP00
Product/component type
ZVI terminal block
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Colour
Blue/light blue
Color
Blue/light blue
Width
16 мм
Width/connection pitch
16.0 мм
