IEK
ARMAT RCBO B06S 1P+N C16 30mA type A (18mm) IEK AR-B06S-1N-C16A030
SKU: AR-B06S-1N-C16A030
ETIM: EC000905
6,085 ₽
Get back 60 ₽ in points
Analogues by specifications
Stock by warehouse
ARMAT B06S series residual current circuit breakers (RCCB) can provide protection against overload and short-circuit currents, as well as protection of persons against earth leakage currents. The product range includes devices with rated currents from 6 to 32 A, trip characteristics B and C, types AC and A with a rated residual current of 30 mA. The rated breaking capacity of ARMAT B06S series RCCB is 6 kA.
Mounting installation depth
76.2 мм
Overvoltage protection
No
Protection class per GOST IEC 61140
0
Current limiting class
3
Number of protected poles
1
Number of poles
1+N
Maximum supply cable cross-section
10 кв.мм
Mechanical durability
20000
Tightening torque of contact terminal screws
1
Availability of residual current release
Yes
Thermal release available
Yes
Electromagnetic release present
Yes
Electronic release available
No
Rated impulse withstand voltage
4
Rated non-tripping residual current
15
Rated differential making and breaking capacity
6000
Rated breaking capacity per IEC 60947-2
6 кА
Rated voltage
230 В
Rated current
16 А
Rated leakage current
0.03 мА
Total number of poles
2
Breaking capacity per IEC 61009-1
6000
Operating mode
Continuous
Breaking capacity
6.0 кА
Current type
Alternating current (AC)
With switched neutral conductor
Yes
Tripping system
Thermal, electromagnetic
Mounting method
On DIN rail
IP protection rating
IP20
Operating temperature
-25...45
Residual current type
Please provide the text you would like me to translate.
Connection type
Screw connection
Tripping characteristic
It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Frequency (Hz)
50/60 Hz
Width in modular units
1
Electrical wear resistance
10000
